VEKA SLIDE 82 LIFT-AND-SLIDE DOOR
Lift-and-slide Veka doors represent modern and functional solution. As oppose to traditional side-hung doors, sliding sash opens along the fixed element allowing the system to be used in less spacious room. Robust profiles of Veka lift-and-slide doors allow to create large glazed surfaces.
Veka Slide 82 lift-and-slide doors
Lift-and-slide doors system is provided with two rails, which allow comfortable opening of leaves. Opened and unopened leaves can be assembled in various constructions. A special lift-and-slide mechanism , integrated with the control door handle, ensures smooth movement of the leaves along the rail. Double-glass sashes are sealed from both sides with a high-resistance EPDM rubber.
Lift-and-slide doors with good thermal insulation
Lift-and-slide doors of the Veka Slide system provide effective thermal insulation achieved by the use of increased installation depth profile, thermally insulated thresholds, high-quality double-glazing and innovative sealing system.
uPVC made-to-measure windows and doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window or door.
Images are for reference purposes only.
PRODUCT DISCONTINUED.
Discover an alternative to this product:
Installation depth
194 mm
Number of chambers
7 chambers
Heat transfer coefficient
Uf = 1,4 W/m2*K
Profile class
A
Weather stripping
Double external with EPDM rubber, grey/black
Available pane fixations thicknesses
48 mm
Standard glazing
4/16Ar/4 [Rw=32dB, Lt=82%, g=65%]
Standard handle
system handle
Steel thickness
1,5 - 3,0 mm (enclosed in a frame)
Dyed profile core for 2s colors
Yes: brown or caramel core
Warranty
2 years
Certificates
CE
Order processing time
from 4 weeks
Additional parameters
Download technical drawings
Download our catalogue
Lift-and-slide Veka doors represent modern and functional solution. As oppose to traditional side-hung doors, sliding sash opens along the fixed element allowing the system to be used in less spacious room. Robust profiles of Veka lift-and-slide doors allow to create large glazed surfaces.
Veka Slide 82 lift-and-slide doors
Lift-and-slide doors system is provided with two rails, which allow comfortable opening of leaves. Opened and unopened leaves can be assembled in various constructions. A special lift-and-slide mechanism , integrated with the control door handle, ensures smooth movement of the leaves along the rail. Double-glass sashes are sealed from both sides with a high-resistance EPDM rubber.
Lift-and-slide doors with good thermal insulation
Lift-and-slide doors of the Veka Slide system provide effective thermal insulation achieved by the use of increased installation depth profile, thermally insulated thresholds, high-quality double-glazing and innovative sealing system.
uPVC made-to-measure windows and doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window or door.
Images are for reference purposes only.
PRODUCT DISCONTINUED.
Discover an alternative to this product:
| Installation depth | 194 mm |
| Number of chambers | 7 chambers |
| Heat transfer coefficient | Uf = 1,4 W/m2*K |
| Profile class | A |
| Weather stripping | Double external with EPDM rubber, grey/black |
| Available pane fixations thicknesses | 48 mm |
| Standard glazing | 4/16Ar/4 [Rw=32dB, Lt=82%, g=65%] |
| Standard handle | system handle |
| Steel thickness | 1,5 - 3,0 mm (enclosed in a frame) |
| Dyed profile core for 2s colors | Yes: brown or caramel core |
| Warranty | 2 years |
| Certificates | CE |
| Order processing time | from 4 weeks |
