ALUPLAST SMART SLIDE SLIDING DOOR
Aluplast launches the smart-slide sliding doors as a response to the growing demand for the construction which will combine the traditional PSK doors and lift and slide HST doors.
Smart-slide doors allow creating a glazed construction with the leaf dimensions of 1.5 x 2.3 m, in one pattern: A - 2-segment, with one moving leaf.
PVC balcony sliding door
The characteristics of smart-slide construction performance indicate that the doors can be easily used both in residential and commercial buildings. Very good results in the scope of air permeability, wind load resistance and water resistance tests allow using this solution in high-rise buildings and in almost every wind load zone.
HST door operation comfort
The application of solutions similar to the HST construction allows comfortable release of the moving part of the door. After opening, the leaf moves incredibly easily on the trolleys - the handling is very intuitive and easy.
Modern alternative for PSK
Technical properties, including the construction, was borrowed from PSK balcony doors, whereas the comfort of using smart-slide is usually a characteristic feature of HST doors.
Terrace doors with aluminum covers
Smart-slide balcony doors are characterized by a minimalist and subtle design. The depth of the profile is just 66 mm, so the construction seems to be incredibly sleek and elegant. The smart-slide system is available in a wide range of decoration films, with the option of applying aluminium overlays, hence increasing the choice of colours.
uPVC made-to-measure windows
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window. In our offer you will also find Schuco UPVC window.
Images are for reference purposes only.
Installation depth
140mm
Number of chambers
6 chambers
Heat transfer coefficient
Uf = 1,3 W/m2*K
Profile class
B
Weather stripping
TPE
Available pane fixations thicknesses
24 mm - 41 mm
Standard glazing
4/16Ar/4 (Rw=32dB, Lt=80%, g=63%)
Standard handle
Standard
Steel thickness
1,5 - 2,0 mm
Dyed profile core for 2s colors
Yes: white, brown, anthracite
Warranty
2 years*
Certificates
CE
Order processing time
from 3 weeks
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
Aluplast launches the smart-slide sliding doors as a response to the growing demand for the construction which will combine the traditional PSK doors and lift and slide HST doors.
Smart-slide doors allow creating a glazed construction with the leaf dimensions of 1.5 x 2.3 m, in one pattern: A - 2-segment, with one moving leaf.
PVC balcony sliding door
The characteristics of smart-slide construction performance indicate that the doors can be easily used both in residential and commercial buildings. Very good results in the scope of air permeability, wind load resistance and water resistance tests allow using this solution in high-rise buildings and in almost every wind load zone.
HST door operation comfort
The application of solutions similar to the HST construction allows comfortable release of the moving part of the door. After opening, the leaf moves incredibly easily on the trolleys - the handling is very intuitive and easy.
Modern alternative for PSK
Technical properties, including the construction, was borrowed from PSK balcony doors, whereas the comfort of using smart-slide is usually a characteristic feature of HST doors.
Terrace doors with aluminum covers
Smart-slide balcony doors are characterized by a minimalist and subtle design. The depth of the profile is just 66 mm, so the construction seems to be incredibly sleek and elegant. The smart-slide system is available in a wide range of decoration films, with the option of applying aluminium overlays, hence increasing the choice of colours.
uPVC made-to-measure windows
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window. In our offer you will also find Schuco UPVC window.
Images are for reference purposes only.
| Installation depth | 140mm |
| Number of chambers | 6 chambers |
| Heat transfer coefficient | Uf = 1,3 W/m2*K |
| Profile class | B |
| Weather stripping | TPE |
| Available pane fixations thicknesses | 24 mm - 41 mm |
| Standard glazing | 4/16Ar/4 (Rw=32dB, Lt=80%, g=63%) |
| Standard handle | Standard |
| Steel thickness | 1,5 - 2,0 mm |
| Dyed profile core for 2s colors | Yes: white, brown, anthracite |
| Warranty | 2 years* |
| Certificates | CE |
| Order processing time | from 3 weeks |
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
