ALUPLAST ST SLIDING DOOR MULTI SLIDE
Sliding windows are a modern and functional solution available in the Aluplast system. MULTI SLIDE profile makes it possible to create glazed surfaces in residential and commercial building.
Sliding windows and doors
ST System allows convenient movement of the sashes parallel to each other and can consist two or more rails. Double-glass sashes are sealed with brush seals. Due to larger installation depth, high weather resistance and good thermal and sound insulation it is recommended to fit the ST System on the outside of the building. ST system can be successfully used as patio doors alternative. As oppose to traditional side-hung doors, sliding sashes open along each other allowing the system to be used in less spacious room.
Bespoke uPVC sliding windows and doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window or door.
Images are for reference purposes only.
Installation depth
80mm or 96mm
Number of chambers
3 chambers
Heat transfer coefficient
Uf = 2,3 W/m2*K
Profile class
B
Weather stripping
Brush weather seals
Available pane fixations thicknesses
24 mm - 33mm
Standard glazing
4/16Ar/4 (Rw=32dB, Lt=80%, g=63%)
Number of rails
2 or more
Steel thickness
1,5 Sash, 1,25 Frame
Dyed profile core for 2s colors
Yes: brown, white or anthracite core under the veneer
Warranty
2 years*
Certificates
CE
Order processing time
from 3 weeks
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
Sliding windows are a modern and functional solution available in the Aluplast system. MULTI SLIDE profile makes it possible to create glazed surfaces in residential and commercial building.
Sliding windows and doors
ST System allows convenient movement of the sashes parallel to each other and can consist two or more rails. Double-glass sashes are sealed with brush seals. Due to larger installation depth, high weather resistance and good thermal and sound insulation it is recommended to fit the ST System on the outside of the building. ST system can be successfully used as patio doors alternative. As oppose to traditional side-hung doors, sliding sashes open along each other allowing the system to be used in less spacious room.
Bespoke uPVC sliding windows and doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one window or door.
Images are for reference purposes only.
| Installation depth | 80mm or 96mm |
| Number of chambers | 3 chambers |
| Heat transfer coefficient | Uf = 2,3 W/m2*K |
| Profile class | B |
| Weather stripping | Brush weather seals |
| Available pane fixations thicknesses | 24 mm - 33mm |
| Standard glazing | 4/16Ar/4 (Rw=32dB, Lt=80%, g=63%) |
| Number of rails | 2 or more |
| Steel thickness | 1,5 Sash, 1,25 Frame |
| Dyed profile core for 2s colors | Yes: brown, white or anthracite core under the veneer |
| Warranty | 2 years* |
| Certificates | CE |
| Order processing time | from 3 weeks |
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
