Aluplast ID 8000
Aluplast ID 8000 UPVC Windows
Aluplast ID 8000 designed for passive houses represents excellent thermal and acoustic parameters.
Aluplast ID 8000 - windows for passive houses
Low heat transfer coefficient has been achieved through the use of 85 mm, six-chamber profile supported by thermally insulated glazed unit. High-quality triple sealing protects against heat loss and noise. ID 8000 increased glazing rebate allows energy-efficient triple-glazed unit of up to 51mm to be used. Additionally, double thick glazing reduces the heat permeability of the window.
Durable, non-deforming window profiles
Addition of internal, high resistance EPDM rubber seal creates dry chamber – space between frame and sash that occurs when window is closed within which hardware operates. Dry chamber increases durability of hardware offering protection against outside moisture. Solid steel reinforcements mounted in sufficiently large chambers guarantee optimum statics of windows including large-size constructions.
If you are interested in purchasing Aluplast ID 8000 windows - contact our sales representative.
Installation depth
85mm
Number of chambers
6 chambers
Heat transfer coefficient
Uf = 1,0 W/m2*K
Profile class
B
Weather stripping
Triple central with EPDM, grey/black
Available pane fixations thicknesses
24 mm - 52 mm
Standard glazing
4/18Ar/4/18Ar/4 (Rw=33dB, Lt=72%, g=50%)
Standard handle
Hoppe Secustic
Steel thickness
1,25 - 2,0 mm (enclosed in a frame)
Dyed profile core for 2s colors
Yes: brown, white or anthracite core under the venee
Warranty
5 years for the whole window
Certificates
CE
Order processing time
from 2 weeks
Additional parameters
Download technical drawings
Download our catalogue
Aluplast ID 8000 UPVC Windows
Aluplast ID 8000 designed for passive houses represents excellent thermal and acoustic parameters.
Aluplast ID 8000 - windows for passive houses
Low heat transfer coefficient has been achieved through the use of 85 mm, six-chamber profile supported by thermally insulated glazed unit. High-quality triple sealing protects against heat loss and noise. ID 8000 increased glazing rebate allows energy-efficient triple-glazed unit of up to 51mm to be used. Additionally, double thick glazing reduces the heat permeability of the window.
Durable, non-deforming window profiles
Addition of internal, high resistance EPDM rubber seal creates dry chamber – space between frame and sash that occurs when window is closed within which hardware operates. Dry chamber increases durability of hardware offering protection against outside moisture. Solid steel reinforcements mounted in sufficiently large chambers guarantee optimum statics of windows including large-size constructions.
If you are interested in purchasing Aluplast ID 8000 windows - contact our sales representative.
| Installation depth | 85mm |
| Number of chambers | 6 chambers |
| Heat transfer coefficient | Uf = 1,0 W/m2*K |
| Profile class | B |
| Weather stripping | Triple central with EPDM, grey/black |
| Available pane fixations thicknesses | 24 mm - 52 mm |
| Standard glazing | 4/18Ar/4/18Ar/4 (Rw=33dB, Lt=72%, g=50%) |
| Standard handle | Hoppe Secustic |
| Steel thickness | 1,25 - 2,0 mm (enclosed in a frame) |
| Dyed profile core for 2s colors | Yes: brown, white or anthracite core under the venee |
| Warranty | 5 years for the whole window |
| Certificates | CE |
| Order processing time | from 2 weeks |
Additional parameters
Download technical drawings
Download our catalogue
