TILT AND SLIDE DOORS ALUPLAST PSK
Aluplast PSK is a tilt and slide system based on standard Aluplast window and door profiles. Its advantages include a moderate price, high tightness and the potential to create a large glazed surface while maintaining the functionality of the premises.
Aluplast PSK - how it works
Sliding the sashes in the PSK system becomes possible through the use of a special fitting mechanism. After turning the handle from the closed position, the sash slides out into the room, perpendicular to the window plane, and then slides to the side. This type of door also has a tilt function. It is also possible to install assisted tilt adjustment via the handle for even easier use.
Opening options for PSK tilt and slide doors
There are three opening options for PSK tilt and slide doors: 2 - quarters - the sash slides to the left or right fixed quarters, 3 - quarters - the middle moving sash slides to the left or right fixed quarters, 4 - quarters - the two middle sashes slide to the left or right fixed quarters respectively.
Aluplast PSK - convenience of use
PSK tilt and slide doors are a very good alternative to patio doors. They provide sliding as well as tilting of the sash, but do not take up any space inside the room when opened. This saves space in the room and allows free space planning.
Moreover, the PSK tilt and slide system enables smooth and very quiet sliding of even large and heavy doors and, thanks to the tilt and slide function, allows free ventilation of rooms while maintaining a high level of security.
Aluplast PSK doors made to measure
At Aikon Distribution, Aluplast PSK doors are made to measure, i.e. to a customer's special order and specification. This allows us to produce non-standard solutions. What is important is that the customisation option is possible with the purchase of even one window or door.
Installation depth
70mm
Number of chambers
5 chambers
Heat transfer coefficient
Uf = 1,3 W/m2*K
Profile class
B
Weather stripping
Double external with EPDM rubber, grey/black
Available pane fixations thicknesses
24 mm - 41 mm
Standard glazing
4/16Ar/4 (Rw=32dB, Lt=80%, g=63%)
Standard handle
Standard
Steel thickness
1,5 - 2,0 mm
Dyed profile core for 2s colors
Yes: brown, white or anthracite core under the veneer
Warranty
2 years*
Certificates
CE, CEKAL (For the glazing)
Order processing time
from 2 weeks
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
Aluplast PSK is a tilt and slide system based on standard Aluplast window and door profiles. Its advantages include a moderate price, high tightness and the potential to create a large glazed surface while maintaining the functionality of the premises.
Aluplast PSK - how it works
Sliding the sashes in the PSK system becomes possible through the use of a special fitting mechanism. After turning the handle from the closed position, the sash slides out into the room, perpendicular to the window plane, and then slides to the side. This type of door also has a tilt function. It is also possible to install assisted tilt adjustment via the handle for even easier use.
Opening options for PSK tilt and slide doors
There are three opening options for PSK tilt and slide doors: 2 - quarters - the sash slides to the left or right fixed quarters, 3 - quarters - the middle moving sash slides to the left or right fixed quarters, 4 - quarters - the two middle sashes slide to the left or right fixed quarters respectively.
Aluplast PSK - convenience of use
PSK tilt and slide doors are a very good alternative to patio doors. They provide sliding as well as tilting of the sash, but do not take up any space inside the room when opened. This saves space in the room and allows free space planning.
Moreover, the PSK tilt and slide system enables smooth and very quiet sliding of even large and heavy doors and, thanks to the tilt and slide function, allows free ventilation of rooms while maintaining a high level of security.
Aluplast PSK doors made to measure
At Aikon Distribution, Aluplast PSK doors are made to measure, i.e. to a customer's special order and specification. This allows us to produce non-standard solutions. What is important is that the customisation option is possible with the purchase of even one window or door.
Installation depth | 70mm |
Number of chambers | 5 chambers |
Heat transfer coefficient | Uf = 1,3 W/m2*K |
Profile class | B |
Weather stripping | Double external with EPDM rubber, grey/black |
Available pane fixations thicknesses | 24 mm - 41 mm |
Standard glazing | 4/16Ar/4 (Rw=32dB, Lt=80%, g=63%) |
Standard handle | Standard |
Steel thickness | 1,5 - 2,0 mm |
Dyed profile core for 2s colors | Yes: brown, white or anthracite core under the veneer |
Warranty | 2 years* |
Certificates | CE, CEKAL (For the glazing) |
Order processing time | from 2 weeks |
