ALIPLAST GENESIS 75
Three-chamber window and door system with increased thermal performance.
Aliplast Genesis 75 - termally broken aluminium windows
The Aliplast Genesis 75 system takes advantage of just released state-of-the-art insulation materials. In addition to the main window seal it has been designed with an additional seal that improves Genesis 75 thermal performance, providing the profile with very high air and water tightness. The heat transfer coefficient for Genesis windows can be as low as Uf = 0.84 W/m2*K. The Genesis 75 window and door system sets new standards without compromising unparalleled ergonomics.
aliplast GENESIS 75 – A NUMBER OF APPLICATIONS
Genesis 75 profiles are based on a 75mm frame elements allowing different types of windows, shop windows, and exterior doors to be designed. Such variety makes Genesis 75 a popular choice for public buildings as well as architects planning individual projects.
ALUMINIUM WINDOWS WITH ADVANCED GLAZING
Glazing units ranging from 24mm to 56mm are fixed and sealed in the dedicated window and door profiles supported with appropriate aluminium beading and EPDM glazing sealing
Modern window design
Wide range of aluminium profiles, RAL colours as well as wood-like coatings available allow our windows and doors to be individually tailored to any project requirements offering innovative design and improved appearance.
ALUMINIUM WINDOWS TO SIZE AND SPECIFICATION
You can choose wide range of dimensions, colours, number of window sections and combination of sashes and fixed elements as well as additional profiles. With the variety of applications we are also able to supply windows with extra-large dimensions for customised orders. We are experienced in manufacturing curved, triangular, trapezoid, and round windows. Order customisation is available even if just one window is ordered.
Profile thermal performance could be enhanced through application of profile thermal inserts or dedicated glass unit thermal supports.
Check also: Aliplast Imperial Windows
The price of Aliplast Genesis is custom calculated for each order.
Aliplast Genesis 75: Installation depth
75mm
Heat transfer coefficient
Uf = 1.05 W / m2 * K (frame: GN011, sash: GN023)
Profile type
warm
Weather stripping
Double central with EPDM
Available pane fixations thicknesses
9 mm – 65 mm
Standard glazing
4/16Ar/4 [Rw=32dB, Lt=82%, g=65%]
Standard handle
Standard
Warranty
3 years*
Certificates
CE
Order processing time
from 5 - 8 weeks
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
Three-chamber window and door system with increased thermal performance.
Aliplast Genesis 75 - termally broken aluminium windows
The Aliplast Genesis 75 system takes advantage of just released state-of-the-art insulation materials. In addition to the main window seal it has been designed with an additional seal that improves Genesis 75 thermal performance, providing the profile with very high air and water tightness. The heat transfer coefficient for Genesis windows can be as low as Uf = 0.84 W/m2*K. The Genesis 75 window and door system sets new standards without compromising unparalleled ergonomics.
aliplast GENESIS 75 – A NUMBER OF APPLICATIONS
Genesis 75 profiles are based on a 75mm frame elements allowing different types of windows, shop windows, and exterior doors to be designed. Such variety makes Genesis 75 a popular choice for public buildings as well as architects planning individual projects.
ALUMINIUM WINDOWS WITH ADVANCED GLAZING
Glazing units ranging from 24mm to 56mm are fixed and sealed in the dedicated window and door profiles supported with appropriate aluminium beading and EPDM glazing sealing
Modern window design
Wide range of aluminium profiles, RAL colours as well as wood-like coatings available allow our windows and doors to be individually tailored to any project requirements offering innovative design and improved appearance.
ALUMINIUM WINDOWS TO SIZE AND SPECIFICATION
You can choose wide range of dimensions, colours, number of window sections and combination of sashes and fixed elements as well as additional profiles. With the variety of applications we are also able to supply windows with extra-large dimensions for customised orders. We are experienced in manufacturing curved, triangular, trapezoid, and round windows. Order customisation is available even if just one window is ordered.
Profile thermal performance could be enhanced through application of profile thermal inserts or dedicated glass unit thermal supports.
Check also: Aliplast Imperial Windows
The price of Aliplast Genesis is custom calculated for each order.
| Aliplast Genesis 75: Installation depth | 75mm |
| Heat transfer coefficient | Uf = 1.05 W / m2 * K (frame: GN011, sash: GN023) |
| Profile type | warm |
| Weather stripping | Double central with EPDM |
| Available pane fixations thicknesses | 9 mm – 65 mm |
| Standard glazing | 4/16Ar/4 [Rw=32dB, Lt=82%, g=65%] |
| Standard handle | Standard |
| Warranty | 3 years* |
| Certificates | CE |
| Order processing time | from 5 - 8 weeks |
*detailed warranty conditions available from your sales representative
Additional parameters
Download technical drawings
Download our catalogue
